材料結構
頭蓋:316不鏽鋼、316L不鏽鋼
桶身:316不鏽鋼、316L不鏽鋼
内部元件:316不鏽鋼、316L不鏽鋼
桶身密封圈:標準 - Silicone矽橡膠
可選用 - EPDM三元乙丙橡膠、Viton氟橡膠、Teflon Encapsulated Viton 聚四氟乙烯包覆氟橡膠
最大操作壓力
150 psig (10.3 bar) @77°F (25℃) 用於液體過濾。
接口尺寸
進/出水口:1", 2", 3" Ferrule
排氣口:1/2" Ferrule
